Ask the Bike Geek: Spring Tension on TRP Euro-X Brakes

Pin It
TRP Brakes EuroX Cyclocross Cantilever Brakes

TRP Brakes EuroX Cyclocross Cantilever Brakes

We get a bunch of questions about bike setup and tech via email and our forums. Occasionally we’ll seek out answers direct from the manufacturer. Here’s one question from Dave Hutton we received recently.

I am currently a TRP Brakes EuroX user. I love the performance of the cyclocross brakes but I have a nerve problem in my hand from a neck injury I obtained playing football in high school and suffer from weakness and numbing in my fingers still. At times I find the spring tension of the TRP Brakes EuroX a bit stiff…there is a possible swap I could do with another brand’s springs on my TRPs?

Response from Lance Larrabee of TRP Brakes:

The first production of TRP EuroX brakes introduced in 2007 used a relatively firm return spring.  After listening to feedback from shops, consumers and our sponsored athletes, in early 2008 we made a running change to a slightly softer spring.  The softer return springs gave the brakes a feel at the lever closer to the feel of a road caliper brake.

The two different springs are easy to identify, the firm have three complete coils, while the softer springs have two complete coils.

The springs are interchangeable in all models of EuroX, Alloy, Carbon and Magnesium. Pairs of both the soft (two coils) and firm (three coils) springs are sold separately and are available direct from TRP USA. For more info on the EuroX visit the TRP Brakes website.

If you have cyclocross-related tech questions, ask the bike geek here at CXM: [email protected]





Cyclocross Magazine, Issue 22, Print and digital subscriptionsHave you subscribed yet? You're missing out if not. Get all-original content and your cyclocross fix throughout the year with a subscription and Issue 23 back copy, with features on Lars van der Haar, Jonathan Page, Elle Anderson and more!
Tagged as: , , ,
1 comments
Mark Legg-Compton
Mark Legg-Compton

You can decrease the spring tension fairly easily. It comes from the days when MTB's came with cheap plastic cantilevers (200GX) and non-adjusting tension springs to centre the brake
1. Remove the wheel
2. Now push the brake arm or push on the brake pad so it pushes past the spot it would normally contact the rim. This will decrease the spring tension.
3. Do it in small increments and evenly so both springs are even so the brakes remain centred.
It takes a fine touch but if you do too much, then loosen the brake pad and rotate it so you can hyperextend it out (the opposite of what you just did to decrease the tension) this will increase the spring tension.
Keep in mind if the spring tension is too weak it won't return the brake lever to the start position before braking. Also if you get a little mud in the brake cable housing it will cause too much brake cable drag which the brake spring will need to overcome.
If you don't feel confident in trying this find a competent bike shop mechanic who works on cyclocross bikes regularly which is a very very rare thing in life.
